DIY Music Generator with 16 Different Sounds!

Components Used:

• CD4066 IC
• CD4011 IC
• Diode 4148 – 2
• Diode 4007 – 1
• 270k Resistor – 2
• 150 Resistor – 5
• 620K Resistor – 1
• 62K Resistor – 1
• 104 Capacitor – 1
• 8050 Transistor – 1
• 9561 Audio chip
• Slide switch – 4
• Passive Buzzer – 1

Special Thanks to Our Sponser – JLCPCB:

No project is complete without the right tool and materials. That’s why our sponser JLCPCB stepped into provide essential material for the project. JLCPCB is a leading provider of high quality printed circuit board and PCB assembling services.

Simply head over to JLCPCB, Upload your gerber file, select specification and just place your order.

48-Hour Turnaround for 6 Layer PCBs!

$0 for 2u” ENIG. Free Via-in-Pad. High Precision. Sign Up to Get $80 New User Coupons.

How To Order PCB

8050 Transistor

The 8050 transistor, commonly marked as S8050, is a general-purpose NPN BJT (Bipolar Junction Transistor). It’s widely used in low-power amplification and switching circuits, especially in hobby electronics, Arduino projects, and basic consumer devices.

Key Specifications

Parameter	Value
Type	NPN
Package	TO-92
Max Collector-Emitter Voltage (V<sub>CE</sub>)	25 V
Max Collector Current (I<sub>C</sub>)	1.5 A
Power Dissipation	~1 W
DC Gain (hFE)	110 – 400
Transition Frequency (f<sub>T</sub>)	~100 MHz

Pin Configuration (TO-92 Package)

When the flat side faces you and pins point downward:

1 → Emitter (E)
2 → Base (B)
3 → Collector (C)

⚠️ Always verify the pinout from the datasheet or marking, as layout may vary by manufacturer.

Common Applications

• LED driver circuits
• Relay and buzzer drivers
• Audio signal amplification
• Motor switching (small DC motors)
• Arduino / microcontroller output amplification
• Low-cost consumer electronics

Equivalent / Alternative Transistors

• BC547 (lower current)
• BC337
• 2N2222
• C1815 (lower power)

Typical Use Example

Using S8050 as a switch (Arduino + Relay):

• Base → Arduino pin via 1k–4.7kΩ resistor
• Emitter → GND
• Collector → Relay / Load → VCC

Why Use 8050?

✔ High current handling for TO-92
✔ Cheap and easily available
✔ Beginner-friendly
✔ Works well with microcontrollers

9561 Audio Chip (TDA9561) – Clear Explanation

The 9561 audio chip most commonly refers to the TDA9561, a TV audio processor IC widely used in CRT TVs, LCD TVs, and set-top boxes. It is not a power amplifier; instead, it processes and controls audio signals before sending them to an external amplifier.

What Does TDA9561 Do?

The TDA9561 handles:

• Stereo audio processing
• Volume control
• Bass & treble control
• Balance control
• Audio input selection
• Mute & loudness control

All of this is controlled digitally via I²C communication, usually by a TV’s main microcontroller.

Key Specifications (Typical)

Feature	Details
IC Type	Audio Processor
Audio Channels	Stereo (L & R)
Control Method	I²C Bus
Supply Voltage	~8V – 10V
Package	DIP / SMD (varies)
Used With	External power amplifier IC

Common Applications

• CRT television mainboards
• LCD / LED TV audio sections
• Set-top boxes
• Home audio control boards
• Old DVD players

Common Companion ICs

• TDA2030 / TDA2003 – Mono power amplifier
• TDA7265 / TDA7297 – Stereo power amplifier
• LA4440 – Audio power amp (older TVs)

Important Notes

• ❌ Cannot directly drive speakers
• ✅ Requires proper I²C commands to function
• ⚠️ Faulty I²C lines = no sound
• ⚠️ Needs correct supply filtering for noise-free audio

Common Fault Symptoms

• No sound but video OK
• Sound stuck at low volume
• Volume not responding to remote
• Audio present only on headphones
